The Cruise 10 is the top end of the Torqeedo Cruise product line. With 20 HP equivalent power and 25 HP equivalent thrust, this motor is a beast on larger dinghies or sailboats up to 10 tons.
The Cruise 10 is powered by four 26-104 batteries or 8 standard AGM batteries to deliver 10kW of power.
Key Features
|
|
Speed in knots (km/h)* | Range in sm (km)* | Running time in hours: |
|---|---|---|---|
| Slow | 4,2 (7,8) | 35,2 (65) | 08:20 |
| Full throttle | 17,2 (31,9) | 13,7 (25,5) | 00:48 |
Depends on type of boat, load, propeller and conditions. Speed and range indications do not represent a legal guarantee.
|
|
Cruise 10.0 R |
|---|---|
| Input power in watts | 10,000 |
| Propulsive power in watts | 5,600 |
| Comparable petrol outboards (propulsive power) | 20 HP |
| Comparable petrol outboards (thrust) | 25 HP |
| Maximum overall efficiency in % | 56 |
| Static thrust in lbs* | 315 |
| Integrated battery | - |
| Nominal voltage | 48 |
| Final charging voltage | - |
| Total weight in kg | 59.8 (S) / 61.3 (L) / 62.5 (XL) |
| Motor weight without battery in kg | - |
| Weight of integrated battery | - |
| Shaft length in cm | 38.5 (S) / 51.2 (L) / 63.9 (XL) |
| Standard propeller v = speed in km/h at p = power in watts |
v32/p10k |
| Alternative propeller options | v15/p10k |
| Maximum propeller speed in rpm | 1,400 |
| Control | Remote throttle |
| Steering | Provision to connect to standard remote steering; lockable |
| Tilting device | Manual with grounding protection |
| Tilt angle | +-50° |
| Trim device | Manual, 4-step |
| Integrated on-board computer | Yes |
| Stepless forward/reverse drive | Yes |
Torqeedo static thrust measurement is based on internationally accepted ISO standards. Static thrust figures for conventional trolling motors are typically measured differently, which results in higher values. To compare Torqeedo static thrust data with conventional trolling motors, add approximately 50% to the Torqeedo static thrust
Two-year limited warranty
