Road registrable and ready for adventure, on- and off-road. Perfect for the urban commuter who dislikes traffic jams and the weekend adventurer who enjoys the sounds of nature.
DIMENSIONS
Weight excl. power supply: 52.7kg | 116lbs
+2.1kWh battery: 65.7kg | 144.6lbs
+ 3.1kWh battery: 70.7kg | 155.6lbs
Height: 1,040mm | 41” Seat height: 815mm | 32”
Width (handlebars): 820mm | 32.3”
Length: 1,820mm | 72” Wheelbase: 1215mm | 47.8”
PERFORMANCE
Max speed: 50km/h | 30mph (45km/h EU).
BRAKES
UBCO Quadratic² brake system: Hydraulic & regenerative brakes operate together.
DOT approved hydraulic brakes.
203 x 2.3mm rotors.
DOT approved Dash 3 brake lines.
WHEELS
9 gauge stainless steel spokes.
17×1.85” aluminum rims (DOT compliant).
17×2.75” multi-use tires, balanced between street performance and off-road grip (ECE and DOT compliant).
STRUCTURE
Payload (incl. rider): 150kg | 330lbs
Super X step through frame: 7027 alloy.
Front and rear racks standard.
19 drop forged attachment lugs on subframe & rack.
Mechanically switched self-retaining kickstand.
SUSPENSION
130mm front suspension.
120mm rear suspension.
Preload & rebound adjustment.
