Inflatable motor boat NAVIGATOR LP 290BK Description:
Inflatable boat Navigator LP 290BK has been popular with fans of fishing and water recreation for more than 15 years for its high quality and reliability.
This 3-person boat has a U-shaped cylinder with a reinforced transom made of waterproof plywood. The Cylinders are divided into 4 pressurized compartments (nose, left, right, and an inflatable keel). The patented boat shape, thanks to the full cut of the fabric, has 4 circular and 2 longitudinal seams, which ensures high tightness of the cylinders and minimizes seam leakage.
The Navigator Advantage – Navigator Inflatable boat offers:
- The newest joining technology – thermal welding method.
- The original design of the cylinders – shape narrows down to the nose, thus boosts marine performance.
- The minimum number of joining seams.
- Increased tightness and reliability of the cylinders.
- The Longitudinal and circumferential seams are heat-welded.
- The V-shaped keel bottom improves performance and reduces shock loads during wave passage.
- Improved ride quality thanks to hydrodynamic contours.
- The course stabilizers (keel) installed in the stern provide better directional stability.
- Switching to gliding mode starting with 2.5 hp outboard motors (depends on the model).
- High-quality hull material – Boats are made of high-quality boat German PVC Valmex or Plastel produced by Mehler Texnologies with a density of 750 – 1000 g / m2, which ensures their long-term operation without additional processing of seams.
- The movable seat support system is used to comfortably accommodate passengers in the boat.
- The use of a book-type floor greatly speeds up the process of assembling and disassembling the boat.
- Team of professionals. 100% quality control at every technological stage.
- 5 year warranty Follow our news on instagram and facebook!
NAVIGATOR LP 290BK Specifications
- Brand, model · Navigator LP 290BK
- Boat type · Inflatable keel, Book-type floor
- Body material · PVC
- Length overall (ft) · 9,5
- Length inside (ft) · 6,56
- Width overall (ft) · 4,59
- Width inside (ft) · 2,07
- Tube diameter (ft) · 1,25
- Transom type · Reinforced
- Transom height (ft) / S,L · 1,35/S (15")
- Overall weight (lb) · 84
- Floor type · Hard deck with an inflatable keel
- Chamber diameter (ft) · 1,25
- No. of chambers · 4
- Max weight capacity · 680 lbs
- Max passengers · 3
- Max. engine (kw/hp) · 4,5 / 6
Features
- The welded frame of the cylinders is divided into 3 independent pressurized compartments.
- A 9 cm wide rubber protector (teardrop rubbing strake) is glued around the tube.
- A lifeline 8-10 mm thick is mounted around the outer perimeter of the boat.
- Floor-type – book type floor (4-section) 9 mm thick, wooden boards are connected to each other with PVC strips, 1 piece which folds as a flyer/book.
- Reinforced stationary transom made of marine grade water-resistant plywood 18 mm thick is installed under a certain angle to the cylinders to boost performance. The upper part of the transom is equipped with a protective strip, the sides have special motor-mount planks.
- To transport the boat, 2 handles on the ends of the cylinders may be used.
- The universal towing handle in the bow, made of durable plastic, is used for towing and anchoring the boat.
- A towing ring and anchor roller is used to attach the anchor cable to the bow.
- The boat is equipped with a pressure-control safety valve.
Included in Box
Standard complete package of an inflatable boat (LP-series):
- Two movable seats that are easily adjusted along the entire length of the rails.
- Two detachable aluminum oars – 1.4 meters long.
- Inflatable boat foot pump – 6 liters.
- Small repair kit (PVC patch, glue, valve instrument).
- Operation manual.
- Transporting bag for the boat – 1 pc. (fits in a car trunk)
- Transporting bag for book type floor – 1 pc. (fits in a car trunk)
